CIE 190:2010
- Calculation and Presentation of Unified Glare Rating Tables for Indoor Lighting Luminaires
- standard by Commission Internationale de L'Eclairage, 07/01
- Category: CIE
$114.48
$57.00
This report has been prepared to assist luminaire suppliers and lighting designers inthe production of UGR tables for luminaires in preset arrays at 1:1 spacing to heightratio. This data is needed for the verification of conformity to the limiting UGR by theUGR tabular method specified in clause 6.2 of the Standard ISO 8995-1:2002(E)/CIE S 008/E:2001 "Lighting of Workplaces - Part 1: Indoor". The limiting UGR valuesare recommended in clause 5 of this standard. The report makes use of the basicUGR equation, described in CIE 117-1995, gives tables of preset values for thestandard conditions and in step by step describes the calculation process needed togenerate the uncorrected UGR table. The process is further demonstrated by aworked example of UGR calculation for a disymmetric distribution luminaire in a room2H x 4H. The report also gives the uncorrected UGR table for this luminaire whichcan be used to validate software designed for the production of the UGR table.
PDF
All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
Multi-User Access
After purchasing, you have the ability to assign each license to a specific user.
Printable
At any time, you are permitted to make printed copies for your and your members' reference use.
