IEEE 1149.7-2009

  • IEEE Standard for Reduced-Pin and Enhanced-Functionality Test Access Port and Boundary-Scan Architecture
  • standard by IEEE, 02/10/2010
  • Category: IEEE

$341.00 $171.00

New IEEE Standard - Active.This specification describes circuitry that may be added to an integrated circuit to provide access to on-chip Test Access Ports (TAPs) specified by IEEE Std 1149.1TM-2001. The circuitry uses IEEE 1149.1-2001 as its foundation, providing complete backward compatibility, while aggressively adding features to support test and applications debug. It defines six classes of 1149.7 Test Access Ports (TAP.7s), T0¿¿¿T5, with each class providing incremental capability, building on that of the lower level classes. Class T0 provides the behavior specified by 1149.1 from startup when there are multiple on-chip TAPs. Class T1 adds common debug functions and features to minimize power consumption. Class T2 adds operating modes that maximize scan performance. It also provides an optional hot-connection capability to prevent system corruption when a connection is made to a powered system. Class T3 supports operation in either a fourwire Series or Star Scan Topology. Class T4 provides for communication with either a two-pin or four-pin interface. The two-pin operation serializes 1149.1 transactions and provides for higher Test Clock rates. Class T5 adds the ability to perform data transfers concurrent with scan, supports utilization of functions other than scan, and provides control of TAP.7 pins to custom debug technologies in a manner that ensures current and future interoperability.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.
