• IEEE C57.12.70-2011

IEEE C57.12.70-2011

  • IEEE Standard for Standard Terminal Markings and Connections for Distribution and Power Transformers
  • standard by IEEE, 02/07/2012
  • Category: IEEE

$126.00 $63.00

Revision Standard - Active.Standard terminal markings and connections are described for single-phase and three phase distribution, power, and regulating transformers. For terminal markings, it covers sequence designation, external terminal designation, neutral terminal designation, grounded terminal designation, and marking of full and tap winding terminals. Additive and subtractive polarity and parallel transformer operation are described. Connections of single-phase transformers in various configurations and angular displacement of three-phase transformers to connect to various system phase displacements are covered.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
