  • PROCEDURE FOR MEASURING INPUT CAPACITANCE USING A VECTOR NETWORK ANALYZER (VNA)
  • standard by JEDEC Solid State Technology Association, 10/01/2003
  • Category: JEDEC

$53.00 $27.00

This procedure describes a recommended way to measure pin capacitance of devices with SSTL (Stub Series Terminated Logic) interface pins by use of a Vector Network Analyzer. One purpose of this standard procedure is to reduce the lengthy and often inaccurate footnote - usually found around the specification of pin parasitics - to a simple reference to this document. In special cases modifying statements may adjust this procedure to the special needs of certain component.
