• JEDEC JEP172A

JEDEC JEP172A

  • DISCONTINUING USE OF THE MACHINE MODEL FOR DEVICE ESD QUALIFICATION
  • standard by JEDEC Solid State Technology Association, 07/01/2015
  • Category: JEDEC

$62.00 $31.00

Over the last several decades the so called "machine model" (aka MM) and its application to the required ESD component qualification has been grossly misunderstood. The scope of this JEDEC document is to present evidence to discontinue use of this particular model stress test without incurring any reduction in the IC component's ESD reliability for manufacturing. In this regard, the document's purpose is to provide the necessary technical arguments for strongly recommending no further use of this model for IC qualification. The published document should be used as a reference to propagate this message throughout the industry.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
