• JEDEC JESD 22-A111

JEDEC JESD 22-A111

  • EVALUATION PROCEDURE FOR DETERMINING CAPABILITY TO BOTTOM SIDE BOARD ATTACH BY FULL BODY SOLDER IMMERSION OF SMALL SURFACE MOUNT
  • standard by JEDEC Solid State Technology Association, 05/01/2004
  • Category: JEDEC

$59.00 $30.00

The purpose of this test method is to identify the potential wave solder classification level of small plastic Surface Mount Devices (SMDs) that are sensitive to moisture-induced stress so that they can be properly packaged, stored, and handled to avoid subsequent mechanical damage during the assembly wave solder attachment and/or repair operations. This test method also provides a reliability preconditioning sequence for small SMDs that are wave soldered using full body immersion. This test method, may be used by users to determine what classification level should be used for initial board level reliability qualification.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
