• JEDEC JESD 24-6 (R2002)

JEDEC JESD 24-6 (R2002)

  • ADDENDUM No. 6 to JESD24 - THERMAL IMPEDANCE MEASUREMENTS FOR INSULATED GATE BIPOLAR TRANSISTORS
  • Amendment by JEDEC Solid State Technology Association, 10/01/200
  • Category: JEDEC

$47.00 $24.00

This standard describes in detail the method for thermal measurements of Insulated Gate Bipolar Transistors (IGBTs) and is suitable for use both in manufacturing and application of the devices. The method covers both thermal transient and thermal equilibrium measurements for manufacturing process control and device characterization purposes. Properly implemented, JESD24-6 provides a basis for obtaining realistic thermal parametric values that will benefit supplier's internal effectiveness and will be useful to the design and manufacturer of reliable IGBT circuits.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
