• JEDEC JESD 82-23

JEDEC JESD 82-23

  • DEFINITION OF the SSTUA32S869 AND SSTUA32D869 REGISTERED BUFFER WITH PARITY FOR DDR2 RDIMM APPLICATIONS
  • standard by JEDEC Solid State Technology Association, 05/01/2007
  • Category: JEDEC

$74.00 $37.00

This standard defines standard specifications of DC interface parameters, switching parameters, and test loading for definition of the SSTUA32S869 and SSTUA32D869 registered buffer with parity for driving heavy load on high-density DDR2 RDIMM applications. A typical application would be a 36 SDRAM planar DIMM. The SSTUA32S869 and SSTUA32D869 are identical in functionality to the SSTU32S869 and SSTU32D869 devices respectively but specify tighter timing characteristics and a higher application frequency of up to 410MHz.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
