• JEDEC JESD15-3

JEDEC JESD15-3

  • TWO-RESISTOR COMPACT THERMAL MODEL GUIDELINE
  • standard by JEDEC Solid State Technology Association, 07/01/2008
  • Category: JEDEC

$62.00 $31.00

This document specifies the definition and construction of a two-resistor compact thermal model (CTM) from the JEDEC junction-to-case and junction-to-board thermal metrics. The guidance provided in this document only applies to thermal metrics defined in JEDEC standards JESD51-8 and JESD51-12. The scope of this document is limited to single-die packages that can be effectively represented by a single junction temperature.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
