• JEDEC JESD209-4A

JEDEC JESD209-4A

  • Low Power Double Data Rate 4 (LPDDR4)
  • standard by JEDEC Solid State Technology Association, 2015
  • Category: JEDEC

$284.00 $142.00

This document defines the LPDDR4 standard, including features, functionalities, AC and DC characteristics, packages, and ball/signal assignments. The purpose of this specification is to define the minimum set of requirements for JEDEC compliant 4 Gb through 32 Gb for x16x2channel SDRAM devices. This document was created using aspects of the following standards: DDR2 (JESD79-2), DDR3 (JESD79-3), DDR4 (JESD79-4), LPDDR (JESD209), LPDDR2 (JESD209-2) and LPDDR3 (JESD209-3). Committee Item: 1824.42A
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
