• JEDEC JESD22-B110B.01

JEDEC JESD22-B110B.01

  • Mechanical Shock - Device and Subassembly
  • standard by JEDEC Solid State Technology Association, 06/01/2019
  • Category: JEDEC

$54.00 $27.00

Device and Subassembly Mechanical Shock Test Method is intended to evaluate devices in the free state and assembled to printed wiring boards for use in electrical equipment. The method is intended to determine the compatibility of devices and subassemblies to withstand moderately severe shocks. The use of subassemblies is a means to test devices in usage conditions as assembled to printed wiring boards. Mechanical Shock due to suddenly applied forces, or abrupt change in motion produced by handling, transportation or field operation may disturb operating characteristics, particularly if the shock pulses are repetitive. This is a destructive test intended for device qualification. This document also replaces JESD22-B104.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
