• JEDEC JESD223D

JEDEC JESD223D

  • Universal Flash Storage Host Controller Interface (UFSHCI)
  • standard by JEDEC Solid State Technology Association, 01/01/2018
  • Category: JEDEC

$141.00 $71.00

This standard describes a functional specification of the Host Controller Interface (HCI) for Universal Flash Storage (UFS). The objective of UFSHCI is to provide a uniform interface method of accessing the UFS hardware capabilities so that a standard/common Driver can be provided for the Host Controller. The common Driver would work with UFS host controller from any vendor. This standard includes a description of the hardware/software interface between system software and the host controller hardware. It is intended for hardware designers, system builders and software developers. This standard is a companion document to [UFS], Universal Flash Storage (UFS). The reader is assumed to be familiar with [UFS], [MIPI-UNIPRO], and [MIPI-M-PHY].
Clause 4 provides a brief overview of the architectural overview of UFS. Clause 5 describes the register interface of UFSHCI. Clause 6 describes the data structure used by UFSHCI. Clause 7 provides a theory of operation for UFSHCI. Clause 8 describes the error recovery process for UFSHCI.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
