• JEDEC JESD248

JEDEC JESD248

  • DDR4 NVDIMM-N Design Standard
  • standard by JEDEC Solid State Technology Association, 09/01/2016
  • Category: JEDEC

$87.00 $44.00

This standard defines the electrical and mechanical requirements for 288-pin, 1.2 Volt (VDD), Double Data Rate, Synchronous SDRAM Nonvolatile Dual In-Line Memory Modules with NAND Flash backup (DDR4 NVDIMM-N). A DDR4 NVDIMM-N is a Hybrid Memory Module with a DDR4 DIMM interface consisting of DRAM that is made nonvolatile through the use of NAND Flash. NVDIMM-N modules adhere to the Byte Addressable Energy Backed Interface Standard, JESD245, that provides detailed logical behavior, interface, and register definitions. These DDR4 NVDIMM-N modules are intended for use as main memory or storage when installed in PCs. Item 2233.27
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
