• JEDEC JESD250A

JEDEC JESD250A

  • Graphics Double Data Rate (GDDR6) SGRAM Standard
  • standard by JEDEC Solid State Technology Association, 07/01/2018
  • Category: JEDEC

$228.00 $114.00

JEDEC JESD250A defines the Graphics Double Data Rate 6 (GDDR6) Synchronous Graphics Random Access Memory (SGRAM) specification, including features, functionality, package, and pin assignments. The purpose of this Specification is to define the minimum set of requirements for 8 Gb through 16 Gb x16 dual channel GDDR6 SGRAM devices. System designs based on the required aspects of this standard will be supported by all GDDR6 SGRAM vendors providing compatible devices. Some aspects of the GDDR6 standard such as AC timings and capacitance values were not standardized. Some features are optional and therefore may vary among vendors. In all cases, vendor data sheets should be consulted for specifics. This document was created based on some aspects of the GDDR5 Standard (JESD212). Item 1836.99.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
