JEDEC JESD51-10
- TEST BOARDS FOR THROUGH-HOLE PERIMETER LEADED PACKAGE THERMAL MEASUREMENTS
- standard by JEDEC Solid State Technology Association, 07/01/2000
- Category: JEDEC
$56.00
$28.00
This standard covers the design of printed circuit boards (PCBs) used in the thermal characterization of Dual-Inline Packages (DIP) and Single-Inline Packages (SIP). It is intended to be used in conjunction with the JESD51 series of standards that cover the test methods and test environments. JESD51-10 was developed to give a figure-of-merit of thermal performance that allows for accurate comparisons of packages from different suppliers. It can be used to give a first order approximation of system performance and, in conjunction with the other JESD51 PCB standards, allows for comparisons of the various package families.
