• JEDEC JESD51-14

JEDEC JESD51-14

  • INTERFACE TEST METHOD FOR THE MEASUREMENT OF THE THERMAL RESISTANCE JUNCTION-TO-CASE OF SEMICONDUCTOR DEVICES WITH HEAT FLOW TRO
  • standard by JEDEC Solid State Technology Association, 11/01/2010
  • Category: JEDEC

$80.00 $40.00

This document specifies a test method (referred to herein as "Transient Dual Interface Measurement") to determine the conductive thermal resistance "Junction-to-Case" R0JC (0JC) of semiconductor devices with a heat flow through a single path, i.e., semiconductor devices with a high conductive heat flow path from the die surface that is heated to a package case surface that can be cooled by contacting it to an external heat sink.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
