• JEDEC JESD51-5

JEDEC JESD51-5

  • EXTENSION OF THERMAL TEST BOARD STANDARDS FOR PACKAGES WITH DIRECT THERMAL ATTACHMENT MECHANISMS
  • standard by JEDEC Solid State Technology Association, 02/01/1999
  • Category: JEDEC

$48.00 $24.00

This extension of the thermal standards provides a standard fixture for direct attach type packages such as deep-downset of thermally tabbed packages. This specification provides additional design detail for use in developing thermal test boards with application to these package types. This document is in addition to and not replacement for the design specifications in other standards.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
