• JEDEC JESD51-7

JEDEC JESD51-7

  • HIGH EFFECTIVE THERMAL CONDUCTIVITY TEST BOARD FOR LEADED SURFACE MOUNT PACKAGES
  • standard by JEDEC Solid State Technology Association, 02/01/1999
  • Category: JEDEC

$53.00 $27.00

This fixturing further defines the environment for thermal test of packaged microelectronic devices. Its function is to provide an alternate mounting surface for the analysis of heat flow in electronic components. The objective of the standard is to provide a high effective thermal conductivity mounting surface that can be compared equally against standard tests done in different laboratories with typical variations of less than or equal to 10%.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
