• JEDEC JESD8-14A.01

JEDEC JESD8-14A.01

  • 1.0 V +/- 0.1 V (NORMAL RANGE) AND 0.7 V - 1.1 V (WIDE RANGE) POWER SUPPLY VOLTAGE AND INTERFACE STANDARD FOR NONTERMINATED DIGI
  • standard by JEDEC Solid State Technology Association, 09/01/2007
  • Category: JEDEC

$53.00 $27.00

This new standard provides specifications that will be used by several companies in new 1.0 V products designed in 0.10-0.12 um CMOS technologies, and in components that interface with them. This standard defines power supply voltage ranges, dc interface and switching parameters for a high speed, low voltage family of nonterminated digital circuits driving/driven by parts of the same family, or mixed families which comply with the input receiver specifications. The specifications in this standard represent a minimum set of interface specifications for CMOS compatible circuits. This version is a minor editorial revision as noted in Annex A.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
