MSS SP-152-2017
- Knife Gate Valves for Double Block and Bleed
- standard by Manufacturers Standardization Society, 11/01/2017
- Category: MSS
$94.00
$47.00
1. SCOPE AND FIELD OF APPLICATION
1.1 This Standard Practice covers cast or fabricated, bonneted or bonnetless knife gate valves designed and manufactured to serve as a "Double Block and Bleed" single valve system in pipelines. These valve types shall have flanged body designs compatible with ASME B16.5 flanges for NPS 2 (DN 50) through NPS 24 (DN 600), ASME B16.47 Series A flanges for NPS 26 (DN 650) through NPS 36 (DN 900), and ASME B16.42 for sizes greater than NPS 36 (DN 900).
1.2 The valves identified in this Standard Practice are intended for use in applications where a "Double Block and Bleed" type of isolation is required, and where two (2) individual isolation valves with a removable or drain-containing spool piece between them is typically used.
NOTE: For the purposes of this Standard Practice, "Double Block and Bleed" refers to a valve (or valve application) with two seating surfaces that, in the closed position, provides a seal against pressure from both ends of the valve with a means of venting/bleeding the cavity between the seating surfaces.
1.1 This Standard Practice covers cast or fabricated, bonneted or bonnetless knife gate valves designed and manufactured to serve as a "Double Block and Bleed" single valve system in pipelines. These valve types shall have flanged body designs compatible with ASME B16.5 flanges for NPS 2 (DN 50) through NPS 24 (DN 600), ASME B16.47 Series A flanges for NPS 26 (DN 650) through NPS 36 (DN 900), and ASME B16.42 for sizes greater than NPS 36 (DN 900).
1.2 The valves identified in this Standard Practice are intended for use in applications where a "Double Block and Bleed" type of isolation is required, and where two (2) individual isolation valves with a removable or drain-containing spool piece between them is typically used.
NOTE: For the purposes of this Standard Practice, "Double Block and Bleed" refers to a valve (or valve application) with two seating surfaces that, in the closed position, provides a seal against pressure from both ends of the valve with a means of venting/bleeding the cavity between the seating surfaces.
