• MSS SP-60-2017

MSS SP-60-2017

  • Connecting Flange Joints Between Tapping Sleeves and Tapping Valves
  • standard by Manufacturers Standardization Society, 05/01/2017
  • Category: MSS

$75.00 $38.00

PURPOSE

The purpose of this Standard Practice is to prevent interface and interference problems between tapping sleeves and tapping valves through the use of a positioning recess and mating raised face of the connecitng flanges between tapping sleeves and tapping valves. The recess and raised face serve to ensure proper alignment of the tapping valve onto the tapping sleeve but do nto affect the strength or the tighness of the joint.
SCOPE
1.1 This Standard Practice establishes flange and gasket dimensions which define the interface betweentapping sleeves and tapping valves.
1.2 This Standard Practice establishes dimensions for these special connecting flanges and gaskets ofnominal sizes from NPS 2 through NPS 60 (DN 50 through DN 1500) for water and sewerage systems.
1.3 This Standard Practice establishes pressure-temperature ratings for the connecting flanges.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
