• PIP ELIGD000

PIP ELIGD000

  • Grounding Installation Details [Complete Revision]
  • standard by Process Industry Practices, 05/01/2018
  • Category: PIP

$1,075.00 $538.00

The purpose of this Practice is to provide the typical details for construction of grounding systems in chemical and refining facilities. The bonding and grounding design and installation shall be in accordance with the National Electrical Code. These installation details include power system and equipment grounding, static grounding protection for equipment in classified locations, grounding electrode connections, and step and touch potential grounding. Not included in the scope of this Practice are computer and control system grounding and cathodic protection.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
