• PIP RESP002

PIP RESP002

  • Design of ASME B73.1 and General Purpose Pump Baseplates [Complete Revision]
  • standard by Process Industry Practices, 05/01/2017
  • Category: PIP

$150.00 $75.00

This Practice provides the minimum requirements for ASME B73.1 pump baseplates and baseplates for general purpose pumps.
Comment: The function of a baseplate is to provide a structure under a pump and its driver that maintains alignment between the two components while accepting published piping loads. A pump properly supported and installed improves pump reliability and extends the operating life of such components as bearings, couplings, and seals.
This Practice describes minimum requirements for horizontal pump baseplates that are not covered in the API standards.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
