• PIP VEDST003 (R2007)

PIP VEDST003 (R2007)

  • Shell and Tube Heat Exchanger Specification Sheet (Reaffirmed February 2007)
  • standard by Process Industry Practices, 06/01/1999
  • Category: PIP

$85.00 $43.00

The purpose of this Practice is to provide instruction and/or direction to designers for preparation of the Shell and Tube Heat Exchanger Specification Sheet (hereafter referred to as the Specification Sheet). The Specification Sheet, prepared in conjunction with PIP VECV1001 and PIP VESV1002, completes a specification suitable for obtaining comprehensive bids and subsequent purchase of shell and tube heat exchangers. Note that PIP VEDV1003, Vessel Drawing/Data Sheet and Instructions, does not apply to shell and tube heat exchangers.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
