• SAE AIR5992

SAE AIR5992

  • Descriptions of Systems Integration Test Rigs (Iron Birds) For Aerospace Applications
  • standard by SAE International, 10/16/2015
  • Category: SAE

$81.00 $41.00

This Aerospace Information Report (AIR) provides information on systems integration rigs, commonly referred to as "Iron Birds" for aerospace applications:

a. It includes background historical information including descriptions of Iron Birds produced to date, important component elements and selection rationale, hydraulic system design and operational modes and illustrates the design approaches to be considered.

b. It provides illustrations of the various systems that should be considered for Iron Bird testing in the development phase and utilization during the production program.

c. It includes recommendations for simulation, component development tests, system integration and lessons learned.

The information conveyed in this AIR is intended to help aircraft systems designers to design and develop Iron Birds for Aerospace applications. The document describes the design approaches that should be considered and provides descriptions of Iron Birds produced to date on various commercial and military programs.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
