  • Balancing Machines: Tooling Design Criteria
  • standard by SAE International, 05/20/2016
  • Category: SAE

$81.00 $41.00

This document establishes general design criteria, tolerances, and limits of application for tooling, fixtures and accessories for mounting and driving gas turbine engine rotors on horizontal and vertical balancing machines.

For your own safety, while using balancing tooling, regard the safety instructions of the individual supplier.

The purpose of this document is to provide a set of tooling and fixture design parameters for balancing machine tooling that will facilitate the understanding of the high degree of readout accuracy and precision balance required for turbine engine rotors, and will assist in achieving compliance with the testing requirements as listed in applicable ARP specifications for balancing.
