  • Aerospace Size Standard for Oversize O-rings
  • standard by SAE International, 11/22/2013
  • Category: SAE

$81.00 $41.00

This SAE Aerospace Standard (AS) is applicable to military and commercial aircraft. It specifies the dimensions, tolerances and size codes (dash numbers) for use in glands per MIL-G-5514 where squeeze at low temperature is often insufficient to provide a leak-tight seal. The dimensions and tolerances specified in this standard are suitable for any elastomeric material.

This standard should not be used as a part standard, therefore no part numbers like AS5798-001X shall be created.

Each dash number, which should be appended to an appropriate drawing or standard number, identifies one size O-ring only. An AS5798 sized O-ring is intended to replace an AS568 sized O-ring of the same dash number. An X suffix is part of the dash number to signify oversize.

Temperature limitations of 275 \mDF (135 \mDC) and coefficient of thermal expansion of 9.0 x 10-5 unit length per \mDF (1.6 x 10\u-\u4 unit length per \mDC) were used for swell calculations. Applications that exceed these values should be evaluated for excessive gland fill.
