• SAE J1134_201708

SAE J1134_201708

  • SAE Nodal Mount (Stabilized: Aug 2017)
  • standard by SAE International, 08/14/2017
  • Category: SAE

$81.00 $41.00

This SAE Recommended Practice establishes a single bolt pattern for the No. 1 clutch housing (see Figure 1) and the No. 2 clutch housing (see Figure 2).

These four bolt patterns are designated to give commonality of mounting brackets in existing frame rails.

The 420 mm (16.5 in) span, pad face to pad face, allows the ease of installation in existing frame rail widths. This is also the minimum spacing which will accommodate commonly used clutches.

PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
