• SAE J2577_201007

SAE J2577_201007

  • Heavy Duty Lamp Electrical Connector Standard
  • standard by SAE International, 07/07/2010
  • Category: SAE

$81.00 $41.00

This SAE Standard encompasses connectors that form the electrical interface(s) between the heavy duty lighting device(s) and the truck and truck/trailer wiring harness system. This document provides design and performance requirements based upon the mechanical, electrical and environmental conditions and covers applications of connectors for direct current electrical systems of 24 V nominal or less in heavy-duty signaling and marking devices. This standard excludes forward lighting devices (i.e. fog lamps) but includes the following list of lamps: Stop Lamps; Back Up Lamps; Tail Lamps; Side-Turn Signal Lamps; Turn Signal/Hazard Warning Lamps; Work Lamps; Side Marker Lamps; License Lamps; Clearance Lamps; Chassis Component Status (ABS) Lamps; Identification Lamps.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
