• SMPTE 409M-2005

SMPTE 409M-2005

  • Digital Television Recording - 12.65-mm Type D-16 Format
  • standard by Society of Motion Picture and Television Engineers,
  • Category: SMPTE

$150.00 $75.00

This standard specifies the track content, format, and recording method of the data blocks containing compressed video, AES3 audio data, and associated data which form the helical records on 12.65-mm tape in cassettes. This standard supports recording of source picture formats using 1920 x1080 pixels with the 4:4:4 and 4:2:2 sampling structure specified in SMPTE 274M at the frame rate of 23.98 Hz, 24 Hz, 25 Hz, and 29.97 Hz, and using 1280x720 pixels with the 4:2:2 sampling structure specified in SMPTE 296M at the frame rates of 50 Hz and 59.94 Hz (see note). This standard also supports recording of 12 channels of AES3 audio data and 3 lines of uncompressed blanking interval data. This standard includes packetizing and shuffling operations supporting picture compression using the DCT and DPCM encoding methods defined by ISO/IEC 14496-2 (MPEG-4 simple studio profile). NOTE ? Early implementations of this standard might not comply to the frame rate of 50Hz as specified in SMPTE 296M.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
