• SMPTE RP 174-1993

SMPTE RP 174-1993

  • Bit-Parallel Digital Interface for 4:4:4:4 Component Video Signal (Single Link)
  • standard by Society of Motion Picture and Television Engineers,
  • Category: SMPTE

$75.00 $38.00

This practice describes the means of interconnecting digital video equipment operating in system M (525/60) and complying with the 4:4:4 encoding parameters as defined in CCIR Recommendation 601-2, annex 1 with a nominal sampling frequency of 13.5 MHz. Provision is made to convey signal at 10-bit precision and to carry a fourth, auxiliary, channel as part of the signal multiplex (yielding 4:4:4:4 or 4x4 overall). The practice has application in the television studio over distances up to 100 m (320 ft).
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
