• SMPTE ST 2081-12:2016

SMPTE ST 2081-12:2016

  • 4320-line and 2160-line Source Image and Ancillary Data Mapping for Quad-link 6G-SDI
  • standard by Society of Motion Picture and Television Engineers,
  • Category: SMPTE

$175.00 $88.00

This standard defines the mapping of:
  • MODE 1: 4320-line Y′C′BC′R4:2:2 and 4:2:0 10-bit image formats and ancillary data on a Quad-link 6 Gb/s [nominal] SDI bit-serial interface.
  • MODE 2: 2160-lineR′G′B′, Y′C′BC′R4:4:4(:4) 10-bit and 4:4:4 12-bit image formats and ancillary data on a Quad-link 6 Gb/s [nominal] SDI bit-serial interface.
  • MODE 3: 2160-line Y′C′BC′R4:2:2 and 4:2:0 10-bit Additional Frame Rate Source image formats and ancillary data on a Quad-link 6 Gb/s [nominal] SDI bit-serial interface.
This standard also defines the carriage of the SMPTE ST 352 payload IDs for the Quad-link 6Gb/s SDI interface.
It is not necessary for implementations to include support for all formats that are included in this Standard. Implementers should indicate supported formats in commercial publications.
PDF

All of our standards document are available in PDF (Portable Document Format), an electronic, downloadable format.You will be able to download the file in your account downloads.

Multi-User Access

After purchasing, you have the ability to assign each license to a specific user.

Printable

At any time, you are permitted to make printed copies for your and your members' reference use.
