• SMPTE ST 2082-12:2016

SMPTE ST 2082-12:2016

  • 4320-line and 2160-line Source Image and Ancillary Data Mapping for Quad-link 12G-SDI
  • standard by Society of Motion Picture and Television Engineers,
  • Category: SMPTE

$175.00 $88.00

1 ScopeThis Standard defines the mapping of:
  • MODE 1: 4320-line Source image formats and ancillary data into a Quad-link 12 Gb/s [nominal] SDI bit-serial interface
  • MODE 2: 2160-line Y′C′BC′R or R′G′B′ 4:4:4:4 10-bit or 4:4:4 10-bit or 12-bit Additional Frame Rate (AFR) Source image formats and ancillary data into a Quad-link 12 Gb/s [nominal] SDI bit-serial interface
This Standard also defines the carriage of the SMPTE ST 352 payload ID’s for the Quad-link 12Gb/s SDI interface.
It is not necessary for implementations to include support for all formats that are included in this Standard. Implementers should indicate supported formats in commercial publications.
